Bosch Bosch vg5-613-ecs autodome 600 series 28x pal outdoor lifting camera

Vg5-613-ecs autodome 600 series 28x pal outdoor lifting camera

Analog 28x pal camera, outdoor hoisting protective cover (with transparent acrylic plexiglass spherical cover)

Business type: vg5-613-ecs

Product No.: f.01u two hundred and seventeen point six nine five



Autodome 600 series analog PTZ camera

Choice of 550 TVL 36x or 28x day/night cameras with 12x digital zoom and wide dynamic range

Progressive scan provides smooth and clear images when viewing details in a moving image

Sodium Vapor White Balance mode restores objects to their original color

AutoTrack II automated motion tracking

Advanced privacy masking

Advanced alarm control with rules engine

UTP transmission standard on all models

Cable compensation extends cabling distances

High-impact, heavy-duty, tamper resistant aluminum housing

High-speed 360-degree continuous pan

Preset tour and AutoPan modes

detailed information




Image sensor 1 / 4 inch type exview had CCD (progressive scan)

Effective pixel Pal: about 440000; 752 (horizontal) x 582 (vertical) NTSC: about 380000; 768 (horizontal) x 494 (vertical)

camera lens 36x zoom (3.4 – 122.4 mm) F1 6 to F4 five

Zoom movement speed NTSC, pal

Optical wide angle / optical tele – tracking focus on 4.0 seconds, 4.0 seconds

Optical wide angle / optical tele – tracking focus off 2.7 seconds, 2.7 seconds

Optical wide angle / digital tele 6.0 seconds, 6.2 seconds

Digital wide angle / digital tele 2.1 seconds, 2.3 seconds

focusing Automatic, can be controlled manually

aperture Automatic, can be controlled manually

field 1.7 ° to 57.8 °

Video output 1.0 Vp-p, 75 ohms

gain control Auto / manual / max (– 3 dB to 28 dB, 2 dB steps)

Aperture distortion correction Horizontal and vertical

Digital zoom 12x

Horizontal definition Typically 550 TV lines (NTSC, PAL)

synchronization Line locking (- 120 ° to 120 ° vertical phase adjustment) or internal crystal oscillator clock

Sensitivity (typical) 1 30 IRE , 50 IRE

Day mode

Sensitivity increase off 0.66 lux , 1.4 lux

Sensitivity increase on (NTSC: 1 / 4 second, 15x; PAL: 1 / 3 second, 16.7x) 0.04 lux , 0.1 lux

Night mode

Sensitivity increase off 0.104 lux , 0.209 lux

Sensitivity increase on (NTSC: 1 / 4 second, 15x; PAL: 1 / 3 second, 16.7x) 0.0052 lux , 0.0103 lux

shutter speed 1 / 1 to 1 / 10000 seconds, 22 steps

Signal to noise ratio (SNR) > 50 dB

white balance 2000 K to 10000 K

1. Unless otherwise specified, the test conditions are: F1 6； Shutter = NTSC 1 / 60s, pal 1 / 50s; Maximum AGC; No spherical cover. The transparent spherical cover needs to increase 0.09 aperture loss (90% light transmittance). The colored spherical cover needs to increase 0.47 aperture loss (60% light transmittance).



Image sensor 1 / 4 inch type exview had CCD (progressive scan)

Effective pixel NTSC：380,000 PAL：440,000

camera lens 28x zoom (3.5 – 98.0mm) F1 35 to F3 seven

Zoom movement speed NTSC , PAL

Optical wide angle / optical tele – tracking focus on 2.5 seconds, 2.5 seconds

Optical wide angle / optical tele – tracking focus off 1.7 seconds, 1.7 seconds

Optical wide angle / digital tele – tracking focus on 4.5 seconds, 4.9 seconds

Optical wide angle / digital tele – tracking focus off 1.7 seconds, 1.7 seconds

Digital wide angle / digital tele 2.0 seconds, 2.5 seconds

focusing Automatic, can be controlled manually

aperture Automatic, can be controlled manually

field 2.1 ° to 55.8 °

Video output 1.0 Vp-p, 75 ohms

gain control Auto / manual / max (– 3 dB to 28 dB, 2 dB steps)

Aperture distortion correction Horizontal and vertical

Digital zoom 12x

Horizontal definition 550 TV cable

synchronization Line locking (- 120 ° to 120 ° vertical phase adjustment) or internal crystal oscillator clock

Sensitivity (typical) 2 30 IRE , 50 IRE

Day mode

Sensitivity increase off 0.33 lux , 0.66 lux

Sensitivity increase on (NTSC: 1 / 4 second, 15x; PAL: 1 / 3 second, 16.7x) 0.02 lux , 0.04 lux

Night mode

Sensitivity increase off 0.066 lux , 0.166 lux

Sensitivity increase on (NTSC: 1 / 4 second, 15x; PAL: 1 / 3 second, 16.7x) 0.0026 lux , 0.0082 lux

shutter speed 1 / 1 to 1 / 10000 seconds, 22 steps

Signal to noise ratio (SNR) > 50 dB

white balance 2000 K to 10000 K

2. Unless otherwise specified, the test conditions are: F1 6； Shutter = NTSC 1 / 60s, pal 1 / 50s; Maximum AGC; No spherical cover. The transparent spherical cover needs to increase 0.09 aperture loss (90% light transmittance). The colored spherical cover needs to increase 0.47 aperture loss (60% light transmittance).



Embedded ceiling Indoor hoisting

Horizontal rotation range 360 ° continuous, 360 ° continuous, 360 ° continuous

Pitch angle 1 ° above horizontal, 18 ° above horizontal, 18 ° above horizontal

variable speed 0.1 ° / S - 120 ° / s, 0.1 ° / S - 120 ° / s, 0.1 ° / S - 120 ° / S

Preset bit speed Horizontal rotation: 360 ° / s, vertical pitch: 100 ° / s, horizontal rotation: 360 ° / s, vertical pitch: 100 ° / s, horizontal rotation: 360 ° / s, vertical pitch: 100 ° / S

Preset accuracy ± 0.1 ° (typical), ± 0.1 ° (typical), ± 0.1 ° (typical)

Embedded ceiling Indoor hoisting

input voltage 21-30 VAC 50/60 Hz , 21-30 VAC 50/60 Hz , 21-30 VAC 50/60 Hz

Power consumption, typical 15 W / 27 VA, 15 W / 27 VA, 51 w / 55 VA 3

3. (add 16 watts if vg4-shtr-xt kit is used)

Protect open video Peak current 10 Ka (ceramic gas discharge tube)

Protection on two-phase Peak current 10A, peak power 300W (8 / 20) μ s)

Protection on RS-232 / 485 Electrostatic protection ± 15 kV manikin

Protection on alarm input Peak current 17 A, peak power 300 W (8 / 20) μ s)

Protection on alarm output Peak current 2 A, peak power 300 W (8 / 20) μ s)

Relay output protection on Peak current 7.3 a, peak power 600 W (10 / 1000) μ s)

Power input protection (spherical camera) Peak current 7.3 a, peak power 600 W (10 / 1000) μ s)

Protection power output (hoisting arm power supply) Peak current 21.4 a, peak power 1500 W (10 / 1000) μ s)

VGA-FIBER-AN

explain Multimode fiber module

Compatible receiver LTC 4629 series

Optical fiber compatibility 50 / 125 micron, 62.5/125 micron, low loss multimode glass fiber, rated minimum system bandwidth of 20 MHz

Maximum distance 4.0 km (2.5 miles)

Light budget 14 dB

Connector One (1) st connector

Wavelength (video / data) 850 nm / 1310 nm

Sector / Title 16 independent sectors, each sector can be set with a 20 character title

shelter 24 individually configurable privacy masks

Preset bit 99, 20 character titles can be set for each position

Camera setup / control Dual phase, RS-232, RS-485, bilinx (coaxial cable)

communication protocol Biphasic, bilinx, PELCO P and PELCO D

Patrol route Two (2) types of tour routes: recorded tour routes - two (2) with a total duration of 15 minutes, preset tour routes - one (1) with up to 99 consecutive scenes and one (1) custom tour route with up to 99 scenes

Supported languages English, Czech, Dutch, French, German, Italian, polish, Portuguese, Russian and Spanish

Cable compensation

Maximum distance Precompensation is off and Precompensation is on

RG-59/U 1000 feet (300 meters), 2000 feet (600 meters)

RG-6/U 1500 feet (450 meters), 3000 feet (900 meters)

RG-11/U 2000 feet (600 meters), 4000 feet (1200 meters)

Cat 5 / UTP (passive receiver) 750 feet (225 meters), 1500 feet (450 meters)

Camera power supply 21-30 VAC, 50 / 60 Hz

Heater power supply 21-30 VAC, 50 / 60 Hz

control data Dual phase ± RS-232 Rx / TX or RS-485 ± - optional control data (dial switch can be selected)

video BNC/UTP

Audio line input 9 kohm (typ.), max. 5.5 Vp-p

Eolr alarm input (2) Programmable for "normally open", "normally closed", "normally open monitoring", "normally closed monitoring"

Alarm input (5) Programmable for "normally open" or "normally closed"

Relay output (1) Dry contact rated output: 2 A, 30 VAC

Open collector output (3) Max. 32 VDC, 150 mA

Embedded ceiling Indoor hoisting

Design rating IP54, 4 flame retardant, IP66, NEMA 4x, IP66, NEMA 4x

working temperature - 10 ° C to 40 ° C (14 ° f to 104 ° f), - 10 ° C to 40 ° C (14 ° f to 104 ° f), - 40 ° C to 50 ° C (- 40 ° f to 122 ° f) plus XT Kit: – 60 ° C to 50 ° C (– 76 ° f to 122 ° f)

Storage temperature - 40 ° C to 60 ° C (- 40 ° f to 140 ° f), - 40 ° C to 60 ° C (- 40 ° f to 140 ° f), - 40 ° C to 60 ° C (- 40 ° f to 140 ° f)

humidity 0% to 90% RH, no condensation, 0% to 90% RH, no condensation, 0% to 100% RH, condensation

4. With optional vga-ip54k-ic kit.

Polycarbonate transparent spherical cover VGA-BUBBLE-CCLR

Polycarbonate colored ball cover VGA-BUBBLE-CTIR

hoisting

Polycarbonate transparent spherical cover VGA-BUBBLE-PCLR

Polycarbonate colored ball cover VGA-BUBBLE-PTIR

Transparent high definition acrylic plexiglass VGA-BUBBLE-PCLA

Colored high definition acrylic plexiglass VGA-BUBBLE-PTIA

Lifting arm base

Hanging arm (without transformer) VG4-A-PA0

Hanging arm (120 / 230 VAC transformer) VG4-A-PA1 / VG4-A-PA2

Lifting arm with cable VGA-PEND-ARM

Mounting plate of vga-pend-arm VGA-PEND-WPLATE

Decorative frame for autodome series power supply VG4-A-TSKIRT

Optional mounting plate for boom mounting

Corner mounting plate VG4-A-9542






Autodome 600 series die
